Join Sunny provides high reliability and low cost tiltmeter/tilt sensor to the customers worldwide, the quality and after service are proven to be well guaranteed. Just come and get more details with us.
GSY-TS-12200-Modbus Features:
1. Dual axis monitoring (single axis optional);
2. Full range accuracy 0.001°, resolution 0.0005°;
3. Volume (94*74*64mm) (customizable).
GSY-TS-32600-Modbus Features:
1. Dual axis monitoring (single axis optional);
2. Full range accuracy 0.01°, resolution 0.002°;
3. Volume (94*74*64mm) (customizable).
GSY-TS-3160VO Features:
1. Single axis tilt monitoring;
2. Full range accuracy 0.01°, resolution 0.001°;
3. Output 0~5V, 0~10V (optional).
GSY-TS-4150VO Features:
1. Single axis tilt monitoring;
2. Output: 0-5V, 0-10V (optional);
3. Full range accuracy 0.1°, resolution 0.01°.
GSY-TS-4155CA Features:
1. Single axis tilt monitoring;
2. Full range accuracy 0.1°, resolution 0.01°;
3. Wide voltage input DC 9～36V.
GSY-TS-3165CA Features:
1. Single axis tilt monitoring;
2. Output frequency 5~100HZ (optional);
3. Full range accuracy 0.01°, resolution 0.001°.
GSY-TS-3168CU Features:
1. Single axis tilt monitoring;
2. Full range accuracy 0.01°, resolution 0.001°;
3. Output 4~20mA, 0~20mA, 0~24mA (optional).
GSY-TS-2180VO Features:
1. Single axis tilt monitoring;
2. Output 0~5V, 0~10V (optional);
3. Full range accuracy 0.005°, resolution 0.0007°.
GSY-TM-5140VO Features:
1. Single axis tilt monitoring;
2. Output: 0-5V, 0-10V (optional);
3. Full range accuracy 0.3°, resolution 0.05°.
GSY-TS-5145CA Features:
1. Single axis tilt monitoring;
2. Full range accuracy 0.3°, resolution 0.05°;
3. Output frequency 5~100HZ (optional).
GSY-TS-2185CA Features:
1. Single axis tilt monitoring;
2. Full range accuracy 0.005°, resolution 0.0007°;
3. Output frequency 5~100HZ (optional).
GSY-TS-5146DI Features:
1. Single axis tilt monitoring;
2. Full range accuracy 0.3°, resolution 0.05°;
3. Output frequency 5~100HZ (optional).
GSY-TS-1220DI Features:
1. Two axis tilt monitoring;
2. Full range accuracy 0.001°, resolution 0.0005°;
3. Output frequency 5~100HZ (optional).
GSY-TS-1221DI Features:
1. Two axis tilt monitoring;
2. Output frequency 5~100HZ (optional);
3. Full range accuracy 0.001°, resolution 0.0005°.
GSY-TS-1222VO Features:
1. Two axis tilt monitoring;
2. Output 0~5V, 0~10V (optional);
3. Full range accuracy 0.005°, resolution 0.0007°.
GSY-TS-1225CA Features:
1. Two axis tilt monitoring;
2. Full range accuracy 0.001°, resolution 0.0005°;
3. Output frequency 5~100HZ (optional).
GSY-TS-5148CU Features:
1. Single axis tilt monitoring;
2. Full range accuracy 0.3°, resolution 0.05°;
3. Output 4~20mA, 0~20mA, 0~24mA optional.
GSY-TS-1228AN Features:
1. Two axis tilt monitoring;
2. Output 0~5V、4~20mA (optional);
3. Full range accuracy 0.001°, resolution 0.0005°.
GSY-TS-1230DI Features:
1. Two axis tilt monitoring;
2. Output frequency 5~100HZ (optional);
3. Full range accuracy 0.001°, resolution 0.0005°.
GSY-TS-2186DI Features:
1. Single axis tilt monitoring;
2. Full range accuracy 0.005°, resolution 0.0007°;
3. Output frequency 5~100HZ (optional).
