GSY-QPS-19 Logging Tools Quartz Pressure Sensor
Features
Solid and firm, oil resistant and anti-pollution
Linear measurement, absolute value output
LED lamp diagnostic function
High accuracy, high resolution
Modular and generalized design, easy to maintain
Non contact measurement, no abrasion
Low energy consumption, low temperature drift
Applications
Hydrauli control system
Piston position
Fan pitch angle adjustment
Brake control system
Track spacing detection
Other mechanical positioning and high precision displacement detection device
Specifications
| Specifications | Technique data |
| Stroke length | 0~100…200…300…400…500mm |
| Comprehensive accuracy | ±0.25%F.S, ±0.5%F.S |
| Resolution | 0.03mm |
| Output wire | 2wires/3wires |
| Output signal | 4~20mA, 0~5V, 0~10V, resistance |
| Operating voltage | 12~32VDC |
| Vibrating temperature | -30~85℃ |
| Vibration proof | 10g (5…2000Hz) |
| Strike proof | 50g (11ms) |
| Displacement speed | ≤0.7m/s |
| Insulation resistance | ≥100MΩ (50VDC) |
| Electrical connection | Flying Lead |
| Material | Aluminium alloy |
| IP protection | IP54 |
FAQ:
1. What are the quotation methods?
If you have DHL or Fedex account, we can quote EXW price, otherwise CIF or FOB price.
2. Are there any discounts?
After we submit the sample price, if more quantity is needed, we will quote the bulk price.
3. How long will it take to deliver the goods after placing the order?
For sensors, parts and modules: in stock-one week; no stock-2-4 weeks; For systems, generally, 8-12 weeks.
4. How to deal with the quality problems?
After confirming that the product has quality problems, we will replace it for you free of charge in the shortest possible time.
If interested in Logging Tools Quartz Pressure Sensor, pls contact us: info@joinsunny.cn
