Voltage Type Contactless Angle Sensor
Introduction
GSY-AS-10 magnetic susceptibility angle sensor adopts MEMS technology and is processed by DSP. It can control linear correction, temperature compensation, output signal standardization, digital filtering, zeroing, multi-level different slope settings and programmable intelligent control according to the range to achieve 0~360 °. The current output position is measured in the range of 360°, and the user can set the angle from 4 to 20 mA.
The sensor uses 9V~36V power supply, has reverse and anti-pulse peak voltage protection functions, the measurement error is ±0.3°, the reset repeat accuracy is 0.001mV, and the absolute temperature drift is (±20~50A).
Features
Sampling rate: 1K HZ
Full range accuracy 0.3°
Output 0~5V, 0~10V optional
Wide voltage input DC 9~36V
Wide temperature working -40~+85℃
Angular resolution 0.022°
High vibration resistance >20000g
IP66 protection level
Range 0~360° (optional)
Linearity is 0.15%~0.5%
Applications
Railway gauge
Satellite solar antenna positioning
Towed motor control
Mining machinery, oil logging equipment
Medical equipment
Gimp leveling
Liquid valve: angle actuators
Angle-based control
Various construction machinery angle control
Textile machinery
Specifications
Electrical indicators
| Parameters | Condition | Min | Typical Value | Max | Unit |
| The power supply voltage | / | 9 | 12 | 36 | V |
| Reverse power protection | / | / | 40 | / | V |
| Signal reverse protection | / | / | 40 | / | V |
| The output load | Resistivity | / | 240 | / | Ω |
| Working temperature | / | -40 | / | 85 | ℃ |
| Storage temperature | / | -55 | / | 100 | ℃ |
